Grand General – Single Face Chrome Die Cast Auxiliary Light with Glass Lens

Single Face Chrome Die Cast Auxiliary Light with Glass Lens

The Grand General Single Face Chrome Die Cast Auxiliary Light with Glass Lens delivers classic style and durable performance for any vehicle lighting setup. Built with a rugged chrome die-cast housing and genuine glass lens, this light combines strength, clarity, and timeless design. Engineered for long-term use, it’s ideal for custom builds, show trucks, or functional auxiliary lighting applications.

• Manufacturer: Grand General
• Item Numbers & Colors:78113 – Dark Amber | 78114 – Light Amber
• Material: Chrome die-cast housing with glass lens
• Voltage: 12 V DC
• Wiring: 18-gauge 2-wire hardwired connection
• Mounting Stud: 20-thread, 1/2″ diameter × 1-11/16″ length
• Size: 3-1/2″ Diameter × 4-3/8″ Width × 5-1/2″ Height
• Applications: Auxiliary, marker, or custom exterior light for trucks and trailers

Performance & Fit

This auxiliary light provides dependable illumination and a polished finish that complements any chrome-accented rig. The solid die-cast housing withstands vibration and weather, while the glass lens maintains optical clarity over time. Designed to fit standard 1/2″ stud mounts, it installs easily for reliable lighting wherever needed.

Installation

1. Mount the light to the desired surface using the 1/2″ stud.
2. Connect the two wires: one to power (+) and one to ground (–).
3. Secure wiring and verify illumination before tightening hardware.

Why You’ll Love It

• Durable chrome die-cast housing with authentic glass lens
• Classic single-face design for clean, timeless appearance
• Compatible with standard 1/2″ stud mounts
• Reliable 12 V performance and easy wiring
• Available in Light Amber and Dark Amber lens options

Common Questions

• Is this light sealed? No — it uses a replaceable glass lens for long-term serviceability.
• Does it include the mounting stud? Yes — integrated 1/2″ stud is part of the housing.
• Can it be used as a marker or turn light? Yes — suitable for multiple auxiliary applications.

⚠️ California Proposition 65 Warning:This product can expose you to chemicals including nickel and lead compounds, known to the State of California to cause cancer and reproductive harm.For more information, visit www.P65Warnings.ca.gov.

Note: Available in Light Amber (78114) and Dark Amber (78113). Chrome die-cast housing with glass lens and 18-gauge 2-wire connection.
